Product Description
– LFP(lithium iron phosphate) cell to ensure the highest safety
– Built-In BMS protects the cell such as Temperature, Current, Voltage, SoC
– SoH Extra long cycle life times with 6500 cycles with 80% DoD
– Compatible with most ofthe available lnverters
– Possibility of parallel connection with up to 16 pieces
Product Specifications
| Item | Specification |
|---|---|
| Model | SWA-RMHV-192S100 |
| Nominal Voltage | 614.4Vdc LFP |
| Nominal Capacity | 100Ah |
| Nominal Energy | 61440Wh |
| Operating Voltage Range | 518.4V to 700.8V |
| Discharge Cut-Off Voltage | 480V |
| Max Discharging Current | 100A (Continuous) |
| Peak Discharging Current | 150A / 3s |
| Max Charging Voltage | 700.8V |
| Standard Charging Current | 20A (0.2C) |
| Dimensions | L570 × W440 × H1800 mm |
| Weight | ≈660 Kg |
| Mounting Options | Rack Cabinet |
| Discharging Temperature | -20℃ ~ 55℃ |
| Charging Temperature | 0℃ ~ 45℃ |
| Storage Temperature | 0℃ ~ 35℃ |
| Ingress Rating | IP21 |
| Cycle Life | ＞ 6500 Cycles (0.2C, 25℃ @ 80% DoD) |
