Description
Axpert Ultra 8KW/11KW
2 Inputs & 2 smart outputs
Equipped with 2 Inputs & 2 smart outputs, CT sensor, and user-friendly interface, Axpert Ultra is top-equipped solar inverter. With two independent input power sources – utility and generator – it ensures uninterrupted AC power and incorporates a super large charger (150A) for fast battery charging, even with limited available time from AC or solar sources. In addition, the Axpert Ultra offers a second AC output, enabling users to customize cut-off voltage, state of charge (SoC) percentage, discharge time, and scheduled on/off time.
Main Features
- Dual outputs for smart load management
- Two independent AC power sources connected and switched automatically
- Built-in current transformer sensor to meet self-consumption application
- Support external BTS (Battery Temperature Sensor) detection
- Built-in power status lighting indicators
- Built-in 2.8 colored LCD with slide operation
- Built-in Wi-Fi for mobile monitoring and OTA firmware upgrade
- Supports USB On-the-Go function
- Reserved communication port for BMS (RS485, CAN-BUS or RS232)
- Support optional GFCI, Rapid shutdown, AFCI detections
- Parallel operation with 6 units
| MODEL | Axpert Ultra 8K | Axpert Ultra 11K |
|---|---|---|
| Rated Power | 8000 VA / 8000 W | 11000 VA / 11000 W |
| Parallel Capability | YES, 6 units | |
| INPUT | ||
| Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280 VAC (For Computers); 90-280 VAC (For Home Appliances) | |
| Frequency Range | 50/60 Hz (Auto sensing) | |
| OUTPUT | ||
| AC Voltage Regulation (Batt. Mode) | 230 VAC ± 5% | |
| Surge Power | 16000 VA | 22000 VA |
| Efficiency (Peak) | 0.93 | |
| Transfer Time | 10 ms (For Personal Computers); 20 ms (For Home Appliances) | |
| Waveform | Pure Sine Wave | |
| BATTERY | ||
| Battery Voltage | 48 VDC | |
| Floating Charge Voltage | 54 VDC | |
| Overcharge Protection | 63 VDC | |
| SOLAR CHARGER & AC CHARGER | ||
| Solar Charger Type | MPPT | |
| Maximum PV Array Open Circuit Voltage | 500 VDC | |
| Maximum PV Array Power | 10000W (5000W × 2) | 12000W (6000W × 2) |
| MPPT Range @ Operating Voltage | 90 VDC ~ 450 VDC | |
| Maximum Solar Charge Current | 150A | |
| Maximum AC Charge Current | 120A | 150A |
| Maximum Charge Current | 150A | |
| Maximum PV Input Current | 27A × 2 (MAX 40A) | |
| PHYSICAL | ||
| Dimension, D × W × H (mm) | 145 × 438 × 553.6 | |
| Net Weight (kgs) | 18.4 | |
| Communication Port | USB/RS232/RS485/WiFi/Dry-contact/BTS Support optional GFCI, Rapid shutdown, AFCI detection | |
| External current sensor port | Yes, built-in current transformer sensor | |
| OPERATING ENVIRONMENT | ||
| Operating Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Operating Temperature | -10℃ to 50℃ | |
| Storage Temperature | -15℃ to 60℃ | |
| STANDARD | ||
| Compliance Safety | CE | |
